Features
• SUS304 stainless steel housing
• Bi-directional tripod turnstile with arm drop function
• LED pictograms for intuitive user experience and high throughput in both directions
• High quality at an affordable price
• Low power consumption
• Wide range of accessories
• Easy and simple installation process
• Easy to maintain and monitor
Specifications
- Power requirements AC110V/220V, 50/60Hz
- Power consumption – Starting 68W – Standby 15W – Unlock 60W
- Working temperature -28 °C – 60 °C
- Working humidity 5%-80%
- Working environment Indoor/Outdoor(if sheltered) – Speed of throughput – RFID Maximum 30/minute
- Fingerprint Maximum 25/minute
- Lane width(mm) 500
- Footprint(mm*mm) 520*810
- Dimension(mm) L=520, W=310, H=1010
- Dimension with packing(mm) L=570, W=365, H=1080 – Net weight(kg) 35
- Weight with packing(kg) 36
- LED indicator Y – Cabinet material SUS304 Stainless Steel
- Lid material SUS304 Stainless Steel
- Barrier material SUS304 Stainless Steel
- Barrier movement Rotation
- Emergency mode Y
- Security level Medium
- Mean cycles between failure (MCBF) 1 million – Options/Accessories Counter, SUS316 Cabinet and Lid,
